คำอธิบาย
รายละเอียด:
- High measurement accuracy
- Light weight
- Measures ALL common Metallic Materials
- Wide measuring range: Rockwell B&C, Brinell, Vickers, Shore and HL
- Automatic conversion to Brinell, Rockwell, Vickers and Shore
- Automatic Mean, Min., Max., value display
- Test in any directions
- Impact devices: D, DC, DL, C, D+15, E, G (All impact devices interchangeable)
- Menu operation
- Large LCD display with backlight for low light conditions
- RS 232/USB inter face to PC and micro-printer
- Data management software
- Complies to ASTM A956 and GB/T 17394-1998 Standards
ข้อมูลทางเทคนิค:
- Display: Large graphic LCD with EL backlight for low light conditions
- Accuracy: +/- 0.5% (referred to L = 800; repeated accuracy = +/ – 4 L units)
- Measuring range: HL 200-960 / HRC 19-70 / HRB 13-109 / HB 20-655 / HV 80-1027 / HS 31.9-102.8
- Materials: 9 common metal materials; Wrought and cast steel, Alloy tool steel, Stainless steel, Gray cast iron, Nodular cast iron, Cast aluminum, Brass, Bronze, Wrought copper alloy
- Batteries: 4x 1.5V. AA Alkaline or rechargeable High Capacity batteries
- Operating temperature -10 to +45°C (14 to 113°F)
- Dimensions: 195 x 84 x 38mm (7.7 x 3.3 x 1.5 in.)
- Weight: Basic unit 550g (1.21 lbs)
|
Model
|
HARTIP 3000 |
|---|---|
|
Principle
|
Leeb hardness measurement |
|
Accuracy
|
+/-0.5%@HL=800 |
|
Display
|
Large graphic LCD with EL backlight |
|
Hardness scale
|
HL/HRC/HRB/HB/HV/HS |
|
Measuring range
|
HL200-960 / HRC19-70 / HRB13-109 / HB20-655 / HV80-1027 / HS31.9-102.8 |
|
Impact device
|
D (standard) |
|
Materials
|
9 common metal materials |
|
Memory
|
960 data in 8 blocks |
|
Statistics function
|
Average / Max. / Min. / value |
|
Interface
|
RS232 to PC / Micro-printer |
|
Indicator
|
Low battery |
|
Power off
|
Auto |
|
Power supply
|
1.5v AA battery x 4
|
|
Working environment
|
-40~+80°C (main unit) |
|
Standard
|
ASTM A956
|
|
Dimension (mm)
|
195x84x38 |
|
Net weight (g)
|
550 |
| Material | HL | HRC | HRB | HB | HV | HS |
| Steel & cast steel | 19 – 68 | 38 – 100 | 80 – 683 | 80 – 1027 | 32 – 102 | |
| Cold work tool steel | 20 – 67 | – | – | 80 – 900 | – | |
| Stainless steel | 20 – 62 | 46 – 102 | 85 – 655 | 85 – 800 | – | |
| Grey cast iron | – | – | 93 – 334 | – | – | |
| Nodular cast iron | 174 – 960 | – | – | 130 – 390 | – | – |
| Cast aluminum alloys | – | – | 20 – 160 | – | – | |
| Copper / Zinc alloys (Brass) | – | 13 – 95 | 40 – 173 | – | – | |
| Cu Al / Cu Sn alloys (Bronze) | – | – | 60 – 290 | – | – | |
| Wrought copper alloys | – | – | 45 – 315 | – | – |
